Baropodometric Platforms

Our devices are designed to be the excellence for static, dynamic and stabilometric analysis. In combination with freeStep software, they are the new generation of integrated instruments for postural evaluation and biomechanical analysis. The freeMed modular platforms can meet every clinical and sports need.


Resistive sensors, 24 K gold coated, conductive rubber;

Configurations: 40cm x 40cm up to 300 cm x 50cm;

USB 2.0 interface;

Sampling frequency up to 400Hz in real time.

40x40 60x50 120x50 180x50 240x50 300x50
Alimentation Anna
Current consumption (mA) 50 50 300 300 450 450
Resolution XY 2.5 dpi
Resolution Z 8 bit
Acquisition frequency 5-400Hz selectable
Type of interface USB 2.0
Dimension in mm 440x620 640x740 1240x740 1840x740 2440x740 3040x740
Thickness 8mm
Weight Kg 3,1 4,9 8,5 16 22 30
Type of sensor resistive conductive rubber contacts gold
Type of scanning matrix scan
Calibration 10 bit auto
Suitable temperature working 0°C - 55°C
Maximum pressure 150N/cm2
Sensor Life 1.000.000 of cycles
Product Certification CE
